Name: Ubiquiti UniFi SFP Wizard Bluetooth Transceiver Tester
Brand: Ubiquiti
SKU: UACC-SFP-WIZARD
Price: 1225.00 ZAR
Availability: InStock

Ubiquiti UniFi SFP Wizard Bluetooth Transceiver Tester

0 /5.0 (0 reviews)

SKU UACC-SFP-WIZARD

A pocket tool for checking, testing and reprogramming SFP and QSFP optical modules. It connects to the UniFi mobile app over Bluetooth, runs on a rechargeable battery and shows diagnostics on a small touchscreen.

Key features

Tests and reprograms SFP, SFP+, SFP28, QSFP+ and QSFP28 modules
Bluetooth link to the UniFi mobile app
1.9 inch touchscreen
Rechargeable battery, charges over USB-C
Over-the-air firmware updates

Specifications

Dimensions	90.8 x 52.1 x 20.2 mm; (3.6 x 2.1 x 0.8")
Weight	84 g (3 oz)
Enclosure Material	Polycarbonate
Networking Interface	BLE
Power Method	Li-ion battery
Battery Life	Up to 75 minutes of continuous SFP transceiver diagnostics with laser on, or 35 minutes with QSFP transceivers
Power Supply	Rechargeable Li-ion battery, 3.7V DC, 300mAh
Max. Power Consumption	0.6W
Supported Form Factor	SFP, SFP+, SFP28, QSFP+, QSFP28
LCM Display	1.9" touchscreen
Ambient Operating Temperature	0 to 40° C (32 to 104° F)
Certifications	FCC, IC, CE
