Name: Ubiquiti UISP airMAX AC 5 GHz 22 dBi 45 Degree Sector Antenna (AM-5AC22-45)
Brand: Ubiquiti
SKU: AIR-S522AC
Price: 4195.00 ZAR
Availability: InStock

Ubiquiti UISP airMAX AC 5 GHz 22 dBi 45 Degree Sector Antenna (AM-5AC22-45)

0 /5.0 (0 reviews)

SKU AIR-S522AC

A 22 dBi, 45 degree sector antenna for airMAX AC base stations such as Rocket radios. It covers a narrow slice for point-to-multipoint networks and comes with a pole mount, Rocket bracket and weatherproof RF jumpers.

Key features

22 dBi gain, 5.10 to 5.85 GHz
45 degree horizontal beamwidth
Dual-linear polarisation with 30 dB minimum cross-pol isolation
2 degree electrical downtilt
Pole mount, RocketM bracket and weatherproof RF jumpers included

Specifications

Model	AM-5AC22-45
Frequency range	5.10 to 5.85 GHz
Gain	22 dBi
Beamwidth	45 degrees
Electrical beamwidth	4 degrees
Electrical downtilt	2 degrees
Polarisation	Dual linear
Max VSWR	1.5:1
Dimensions	750 x 215 x 94 mm
Weight	6 kg
Wind survivability	200 km/h
